Wireless EFT POS
ONECLICK K2
The Most Advanced and Innovated ETF-POS
|
ONECLICK K2 PHONE provides many advantages for companies who need solutions for payment & value-added services - including credit, debit, smart cards, prepaid, lottery, gift & proprietary cards.
The terminal suits markets like delivery, conventions, stadium, insurance, transportation services,
|
|
SPECIFICATION
|
Processor & Operating System
|
|
Smart Card
|
|
Microprocessor
|
ARM7 32Bit RISC CPU
|
|
ISO7816,T=0,T=1,EMV LEVEL1
|
|
Operation system
|
RTOS
|
|
PSAM
|
|
Memory
|
|
|
|
Flash Memory
|
1MByte Nor-Flash
|
|
Peripheral Port
|
|
RAM
|
320KByte SRAM
|
|
|
|
Display
|
|
|
|
128x64Pixel, FSTN LCD
|
|
Wireless Modem (Option)
|
|
White LCD Back Light
|
|
Built in CDMA (PCS), GSM/GPRS,3G,LTE available(Optional)
|
|
Touch Panel
|
|
Dimensions
|
|
4 wire analog touch panel
|
|
73.4mm(W) X 138.6mm(L) X47.2mm(H)
|
|
Magnetic Card Reader
|
|
Power
|
|
Magnetic stripe ISO7811,Track II,High Coercivity,Bi-Directional.
|
|
Input : DC 12V~24V Power Input
|
|
Printer
|
|
Environmental
|
|
Thermal graphical printer, Max 384, 58mm wide paper
|
|
Operating Temperature : -20°~ 80
|
|
Improved easy open & easy load mechanism
|
|
Storage Temperature :-30°~90°
|
|
Battery
|
|
Humidity : 5% to 95%
|
|
7.5V, 1350mA
|
|
Audio
|
|
|
|
|
Competitive Features
-
1 years Warranty (The warranty period can be also extended more by a separate agreement.)
-
Long term life time support up to 5 years
-
Long term experiences and know-how accumulated in the fields since 2007.
-
Various options: Built-in wireless such as GSM/GPRS/3G/LTE, Bluetooth, Wi-Fi, NFC, RFID and others and extended serial/digital inputs and outputs, etc.
-
ONECLICK SDK: Provides developers with a convenient and effective way to incorporate credit cards into their solutions.
-
Customization or OEM/ODM is available
|
