Card Reader
ONECLICK M100
The Most Advanced and Innovated Card Reader
|
ONECLICK M100 provides many advantages for companies who need solutions for Card swiping and Sign Pad function. It can work with Coin exchanger and vending machine easily.
The terminal suits markets is any applications need MSR such as Coin exchanger, vending machine, game machine, taxi, store, karaoke machine and etc.
|
|
SPECIFICATION
|
Processor & Operating System
|
|
Dimensions
|
|
Microprocessor
|
Cortex-ARM 32Bit RISC CPU
|
|
79mm(W) X 144mm(L) X48mm(H)
|
|
Key Pad
|
|
Wireless Modem (Option)
|
|
Acrylic Switch 3key,Blue LED backlight
|
|
Can support CDMA, GSM/GPRS, 3G & LTE depend on requirement
|
|
Display
|
|
Power Adapter
|
|
128x64 Gray STN LCD, Yellow Green Backlight
|
|
5V DC 2A/h Adaptor INPUT
|
|
Touch Screen
|
|
Environmental
|
|
4Wire Non-Glare Type
|
|
Operating Temperature : -20°~ 80
|
|
Magnetic Card Reader
|
|
Storage Temperature :-30°~90°
|
|
Magnetic stripe ISO7811,Track II
|
|
Humidity : 5% to 95%
|
|
Peripheral Port
|
|
|
|
Serial Port : 1EA (Baud Rate : 9600pbs)
|
|
|
Competitive Features
-
1 years Warranty (The warranty period can be also extended more by a separate agreement.)
-
Long term life time support up to 5 years
-
Long term experiences and know-how accumulated in the fields since 2007.
-
Various options: Built-in wireless such as GSM/GPRS/3G/LTE, Bluetooth, Wi-Fi, NFC, RFID and others and extended serial/digital inputs and outputs, etc.
-
ONECLICK SDK: Provides developers with a convenient and effective way to incorporate credit cards into their solutions.
-
Customization or OEM/ODM is available
|
